2016 Mercedes-Benz Sprinter Specs, Features & Options
Here's everything you need to know about each trim in the 2016 Mercedes-Benz Sprinter lineup. Compare pricing, specs, key features and more.
1 of 13  Sprinter 2500 Passenger Standard Roof w/144" WB Van 3D | 2 of 13  Sprinter 2500 Cargo Standard Roof w/144" WB Van 3D | 3 of 13  Sprinter 2500 Crew Standard Roof w/144" WB Van 3D | 4 of 13  Sprinter 2500 Cargo High Roof w/144" WB Van 3D | 5 of 13 Sprinter 2500 Cargo High Roof w/170" WB Van 3D | 6 of 13  Sprinter 3500 Cargo Standard w/144" WB Van 3D | 7 of 13  Sprinter 2500 Crew High Roof w/170" WB Van 3D | 8 of 13  Sprinter 2500 Passenger High Roof w/170" WB Van 3D | 9 of 13 Sprinter 2500 Passenger High Roof w/144" WB Van 3D | 10 of 13  Sprinter 3500 Cargo Standard w/170" WB Van 3D | 11 of 13 Sprinter 2500 Crew High Roof w/144" WB Van 3D | 12 of 13 Sprinter 2500 Cargo High Roof Extended w/170" WB Van 3D | 13 of 13 Sprinter 3500 Cargo Extended w/170" WB Van 3D | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Fair Market Price | $25,492 | $26,204 | $27,604 | $28,554 | $30,061 | $31,411 | $31,868 | $32,466 | $32,937 | $33,586 | $33,653 | $34,209 | $36,000 | ||
| Fuel Type | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | ||
| Horsepower | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | 188 @ 3800 RPM | ||
| Seating | 12 | 3 | 5 | 3 | 3 | 3 | 5 | 12 | N/A | 3 | 5 | 3 | 3 | ||
| Cargo Volume | 68.60 cu ft | 319.10 cu ft | 220.10 cu ft | 373.70 cu ft | 486.50 cu ft | 329.30 cu ft | 367.50 cu ft | 190.30 cu ft | 68.60 cu ft | 428.70 cu ft | N/A | 530.00 cu ft | 467.00 cu ft | ||
| Tire Size | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT215/85R16 | LT245/75R16 | LT245/75R16 | LT245/75R16 | LT215/85R16 | LT245/75R16 | LT245/75R16 | LT215/85R16 | ||
| Towing Capacity | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 7,500 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | 7,500 lbs | 5,000 lbs | 5,000 lbs | 5,000 lbs | ||
| Transmission | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | Automatic, 5-Spd | ||
| Curb Weight | 5,644 pounds | 5,038 pounds | 2,796 pounds | 5,104 pounds | 5,434 pounds | 5,534 pounds | 3,237 pounds | 6,228 pounds | 5,644 pounds | 5,908 pounds | N/A | 5,556 pounds | 6,074 pounds | ||
| Dimensions | 233.3" L x 95.5" W x 93.9" H | 233.3" L x 95.5" W x 94.5" H | 233.3" L x 95.5" W x 94.3" H | 233.3" L x 95.5" W x 105.9" H | 274.1" L x 95.5" W x 105.8" H | 233.3" L x 95.5" W x 106.8" H | 274.1" L x 95.5" W x 105.5" H | 274.1" L x 95.5" W x 110" H | 233.3" L x 95.5" W x 110" H | 274.1" L x 95.5" W x 107" H | 233.3" L x 95.5" W x 105.5" H | 289.8" L x 95.5" W x 105.7" H | 289.8" L x 95.5" W x 107.3" H |
| Blind-Spot Alert | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Child Seat Anchors | Standard | Not available | Standard | Not available | Not available | Not available | Standard | Standard | Standard | Not available | Standard | Not available | Not available | ||
| Child Door Locks | Standard | Not available | Not available | Not available | Not available | Not available | Not available | Standard | Standard | Not available | Not available | Not available | Not available |
| Cruise Control | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Remote Keyless Entry | Standard | Not Available | Standard | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | ||
| Navigation System | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Remote Keyless Entry | Standard | Not Available | Standard | Not Available | Not Available | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Standard | ||
| Cruise Control | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Heated Mirrors | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Heated Windshield | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Torque | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM | 325 @ 3800 RPM |
| Third Row Seat | Standard | Not Available | Not Available | Not Available | Not Available | Not Available | Not Available | Standard | Not Available | Not Available | Not Available | Not Available | Not Available |
| Power Outlet | Standard | Optional | Optional | Optional | Optional | Optional | Optional | Standard | Not Available | Optional | Optional | Optional | Optional | ||
| Rear Window Defroster | Standard | Optional | Not Available | Optional | Optional | Optional | Not Available | Standard | Not Available | Optional | Not Available | Optional | Optional | ||
| Tilt Steering Wheel | Standard | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Not Available | Not Available | Standard | Standard | Not Available | ||
| Cup Holder Count | Optional | Not Available | Not Available | Not Available | Not Available | Optional | Standard | Optional | Not Available | Optional | Not Available | Not Available | Optional |
| Alloy Wheels | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Not Available | Not Available | Optional | Optional | Not Available | ||
| Fog Lights | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Privacy Glass | Standard | Optional | Standard | Optional | Optional | Optional | Standard | Standard | Not Available | Optional | Standard | Optional | Optional | ||
| Roof Rails | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional | ||
| Rain Sensing Windshield Wipers | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Alarm System | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Optional | Not Available | Optional | Optional | Optional | Optional |
| Drivetrain | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | RWD | ||
| Hill Start Assist | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Recommended Fuel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | ||
| Stability Control | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Not Available | Standard | Standard | Standard | Standard | ||
| Transmission Type | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic | Automatic |
| Curb Weight | 5644 pounds | 5038 pounds | 2796 pounds | 5104 pounds | 5434 pounds | 5534 pounds | 3237 pounds | 6228 pounds | 5644 pounds | 5908 pounds | Not Available | 5556 pounds | 6074 pounds | ||
| Fuel Capacity | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | 24.5 gallons | ||
| Minimum Ground Clearance | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.8 inches | 7.9 inches | 7.9 inches | 7.9 inches | 7.8 inches | 7.9 inches | 7.9 inches | 7.8 inches | ||
| Overall Length | 233.3 inches | 233.3 inches | 233.3 inches | 233.3 inches | 274.1 inches | 233.3 inches | 274.1 inches | 274.1 inches | 233.3 inches | 274.1 inches | 233.3 inches | 289.8 inches | 289.8 inches | ||
| Payload Capacity | 2906 pounds | 3512 pounds | 3237 pounds | 3446 pounds | 3116 pounds | 4456 pounds | 2796 pounds | 2322 pounds | 2906 pounds | 4082 pounds | Not Available | 2994 pounds | 3916 pounds | ||
| Turning Diameter | 47.6 feet | 44.6 feet | 47.6 feet | 44.6 feet | 51.5 feet | 44.6 feet | 54.8 feet | 54.8 feet | 47.6 feet | 51.5 feet | 47.6 feet | 51.5 feet | 51.5 feet | ||
| Wheel Base | 144.3 inches | 144.3 inches | 144.3 inches | 144.3 inches | 170.3 inches | 144.3 inches | 170.3 inches | 170.3 inches | 144.3 inches | 170.3 inches | 144.3 inches | 170.3 inches | 170.3 inches | ||
| Width with mirrors | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches | 95.5 inches |
All 2016 Mercedes-Benz Sprinter Trims and Styles
- 2016 Mercedes-Benz Sprinter 2500 Passenger Standard Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Cargo Standard Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Crew Standard Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Cargo High Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Cargo High Roof W/170" WB Van 3D
- 2016 Mercedes-Benz Sprinter 3500 Cargo Standard W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Crew High Roof W/170" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Passenger High Roof W/170" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Passenger High Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 3500 Cargo Standard W/170" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Crew High Roof W/144" WB Van 3D
- 2016 Mercedes-Benz Sprinter 2500 Cargo High Roof Extended W/170" WB Van 3D
- 2016 Mercedes-Benz Sprinter 3500 Cargo Extended W/170" WB Van 3D
